This is an ultra-simple, single-file PyTorch implementation of MoonViT, the native-resolution vision encoder from Kimi-VL. ## MoonViT - Pytorch ![Model Architecture](model_arch.png)

This is an ultra-simple, single-file PyTorch implementation of MoonViT, the native-resolution vision encoder from Kimi-VL. I implemented this model because I think it's a great ViT variation with the ability to ingest images of dynamic sizes and resolutions at scale. ## Install ```bash $ pip install open-moonvit ``` Or from source: ```bash $ git clone https://github.com/kyegomez/open-moonvit $ cd open-moonvit $ pip install -e . ``` FlashAttention is optional. If `flash_attn` is importable and you're on CUDA, the var-length kernel is used automatically. Otherwise a block-diagonal SDPA fallback runs on CPU / MPS / CUDA with no extra dependencies. ```bash $ pip install flash-attn --no-build-isolation # optional ``` ## Usage ```python import torch from open_moonvit import MoonViT, MoonViTConfig, MLPProjector encoder = MoonViT(MoonViTConfig()) # ~413M params, SigLIP-SO-400M defaults # a batch of images at different resolutions, no padding, no resizing images = [ torch.randn(3, 224, 280), torch.randn(3, 140, 196), torch.randn(3, 336, 336), ] out = encoder(images) out.last_hidden_state # (L_total, 1152) packed patch tokens out.cu_seqlens # (4,) int32 image boundaries in the packed seq out.grid_shapes # [(16,20), (10,14), (24,24)] ``` To feed an LLM, compose with the MLP projector (2×2 pixel-shuffle then a two-layer MLP): ```python projector = MLPProjector( vision_hidden_size = 1152, llm_hidden_size = 2048, ) tokens, grids, cu = projector(out.last_hidden_state, out.grid_shapes, out.cu_seqlens) tokens.shape # (L_total // 4, 2048) ``` ## How it works ```mermaid flowchart TD A([Images]) --> B[MoonViTPatchEmbed] B --> C[AbsolutePosEmbedInterpolator] subgraph enc[MoonViT] C --> D[MoonViTEncoderLayer × 27] R[RotaryEmbedding2D] -.-> D D --> LN[post LayerNorm] end LN --> PS[PixelShuffle2x] subgraph proj[MLPProjector] PS --> MLP[Linear · Act · Linear] end MLP --> OUT([LLM Tokens]) ``` Four things to internalize: 1. **Packing, not padding.** Images of different shapes become one long sequence. No wasted compute on pad tokens. 2. **Two positional embeddings, added together.** The paper is insistent on this. Interpolated SigLIP absolute pos embed preserves the pretrained prior; 2D RoPE supplies the fine-grained, resolution-robust signal. 3. **Varlen attention is what makes (1) safe.** `cu_seqlens` slices the packed sequence so image *i* only attends to itself. FlashAttention does this in one kernel; the fallback loops per-image over SDPA. 4. **The projector lives outside the encoder.** Pixel shuffle is a 2×2 space-to-depth: four tokens become one, channels 4×. Then a plain two-layer MLP projects into LLM space. ## Why MoonViT over a standard ViT Standard ViTs (ViT-B/L, CLIP ViT, SigLIP) were designed for fixed-resolution square inputs. MoonViT removes that constraint in three meaningful ways: **1. No forced resizing or padding** A standard ViT requires every image to be the same size (e.g. 224×224 or 384×384). To accommodate different aspect ratios you either stretch the image (distorts content) or pad with zeros (wastes compute). MoonViT tokenizes each image at its native `(H, W)` and discards nothing — a 1920×1080 screenshot and a 400×600 portrait can coexist in the same batch without any resizing. **2. Zero padding tokens in the batch** Standard batching pads shorter sequences to the length of the longest. In vision that can mean >50% of the tokens in a batch are meaningless pad values. MoonViT packs all images end-to-end into one flat sequence and uses `cu_seqlens` to mark boundaries, so every token that enters the Transformer carries real signal. This is the NaViT packing strategy applied to a production encoder. **3. Dual positional encoding that survives resolution changes** Most ViTs use a single learnable absolute positional embedding fixed to the pretraining grid size. At inference on a differently-sized image that table has to be interpolated, and fidelity degrades. MoonViT adds a second encoding — 2D RoPE — whose H and W rotation frequencies are computed fresh for every grid size at inference time. The absolute embed preserves the pretrained prior; the RoPE provides the resolution-robust spatial signal. Neither alone is sufficient; both together is what the Kimi-VL paper demonstrates works at scale. | Property | Standard ViT | MoonViT | | --- | --- | --- | | Input resolution | Fixed (e.g. 224×224) | Arbitrary `(H, W)` per image | | Aspect ratio handling | Squash or crop | Native, lossless | | Batch padding tokens | Up to majority of batch | Zero | | Positional encoding | Absolute (interpolated) | Absolute + 2D RoPE | | Cross-image attention leakage | N/A (one image) | Impossible — `cu_seqlens` enforces isolation | | Token count to LLM | `H/p × W/p` | `H/p × W/p ÷ 4` (after pixel-shuffle projector) | ## Citations ```bibtex @article{kimivl2025, title = {Kimi-VL Technical Report}, author = {{Kimi Team}}, journal = {arXiv preprint arXiv:2504.07491}, year = {2025}, url = {https://arxiv.org/abs/2504.07491} } ``` ```bibtex @article{dehghani2023navit, title = {Patch n' Pack: NaViT, a Vision Transformer for any Aspect Ratio and Resolution}, author = {Dehghani, Mostafa and Mustafa, Basil and Djolonga, Josip and Heek, Jonathan and Minderer, Matthias and Caron, Mathilde and Steiner, Andreas and Puigcerver, Joan and Geirhos, Robert and Alabdulmohsin, Ibrahim and Oliver, Avital and Padlewski, Piotr and Gritsenko, Alexey and Lucic, Mario and Houlsby, Neil}, journal = {arXiv preprint arXiv:2307.06304}, year = {2023} } ``` ```bibtex @article{zhai2023siglip, title = {Sigmoid Loss for Language Image Pre-Training}, author = {Zhai, Xiaohua and Mustafa, Basil and Kolesnikov, Alexander and Beyer, Lucas}, journal = {arXiv preprint arXiv:2303.15343}, year = {2023} } ``` ```bibtex @article{su2021roformer, title = {RoFormer: Enhanced Transformer with Rotary Position Embedding}, author = {Su, Jianlin and Lu, Yu and Pan, Shengfeng and Murtadha, Ahmed and Wen, Bo and Liu, Yunfeng}, journal = {arXiv preprint arXiv:2104.09864}, year = {2021} } ``` # License APACHE License 2.0 Source: https://github.com/kyegomez/open-moonvit
