Physics Game for Android

PhyX — Physics Sandbox

1. Project Overview

Type: 2D physics sandbox / destruction simulator
Engine: LÖVE2D (Lua)
Platform: Android (mobile-first), desktop playable

Core concept: place objects made of voxels with material properties. Apply forces (gravity, down-force, explosions, player input). Watch structures fracture, collapse, and interact. ML handles the majority of simulation — stress prediction, fracture propagation, and debris dynamics — working alongside a lightweight traditional physics engine.

Inspired by: People Playground, Garry's Mod, Powder Game, N-Body simulations.

---

2. Visual & Rendering

World

• Background: Dark scientific grid (subtle #0D1117 base with #1E3A5F grid lines, 40px spacing)
• Camera: Scrollable, pinch-to-zoom on mobile; mouse wheel on desktop
• World bounds: Large play area (e.g., 4000×3000 units), walls on all sides

Voxels

• Default size: 8×8 pixels (adjustable per object)
• Each voxel rendered as layered geometric shape:
  1. Outer glow — faint pulsing halo matching material color at 30% opacity
  2. Primary fill — solid material color
  3. Inner detail — material-specific geometric pattern (grain lines for wood, crosshatch for metal, clean glass, etc.)
• Connected voxel groups share a subtle outline at the boundary
• Stress visualization — voxels shift from base color toward red as stress increases

Post-processing (lightweight)

• Screen-edge vignette
• Scanline overlay (subtle, for "scientific readout" aesthetic)
• Particle effects for fractures and debris

UI / HUD

• Toolbar (left side, mobile-friendly large touch targets): material selector (wood, metal, glass, rubber, concrete, explosives)
• Tool mode selector: place / delete / apply force / explode / drag
• Top bar: FPS counter, voxel count, ML status indicator, pause button
• Bottom: force magnitude slider (drag gesture length maps to force)

---

3. Physics Engine Architecture

Traditional Layer (LÖVE2D + Box2D)

Handles core dynamics: gravity, collision detection, rigid body movement, joints.

• PhysicsWorld: wraps love.physics, manages gravity vector, timestep
• Gravity: default (0, 980) — strong downward pull. Configurable per material.
• Down-force: special force mode where player drags down on an object to apply a crushing force
• Collision groups: voxels in the same object share a group (don't collide with each other, but collide with world and other objects)
• Boundary walls: static bodies at world edges

Voxel Grid System

Each object is a grid of voxels:

LUA
Object {
  id, material, voxels[Row][Col] = Voxel | nil,
  body = love.physics.Body,  -- unified rigid body for connected voxels
  fracture_level = 0,       -- current subdivision depth
  stress = 0                -- 0..1, drives fracture
}

Voxel {
  x, y,                  -- world position (top-left of voxel)
  state = "intact" | "fractured" | "removed",
  neighbors = {up, down, left, right},
  stress = 0,            -- accumulated stress
  connections = {},      -- physics joints to neighboring intact voxels
}

Layered Hex-Pixel Discretization (Material Model)

Materials define their fracture depth:

At depth 0: a voxel is the atomic unit — breaks into debris particles.
At depth N: a voxel breaks into a 3×3 grid of sub-voxels (each inherits parent stress).

Fracture Mechanics

1. Stress accumulation: each frame, ML system computes stress across the voxel grid
2. Threshold check: if a voxel's stress > material threshold, it enters "cracking" state
3. Propagation: cracking voxel applies stress to neighbors (cascading for brittle materials)
4. Separation: intact connections are removed, fractured voxels become independent physics bodies
5. Debris: sub-voxels become small rigid bodies with randomized velocity based on impact force

ML Integration Points

The ML system is called from the physics loop at strategic points:

---

4. Neural Network Architecture

Pure Lua implementation, no external dependencies.

Network 1: Stress Predictor

• Input: Voxel grid state — for each voxel: material type (one-hot), intact/fractured (binary), stress value, neighbor count, distance from force application point. Flattened, ~20 features per voxel × N voxels.
• Output: Stress value per voxel (regression, 0..1)
• Architecture: 2 hidden layers, (input/4, input/8) neurons, tanh activation
• Training: Online — collect (grid_state, stress_map) samples from simulation, batch train every N frames
• Use case: Replaces expensive iterative spring-damper stress calculation

Network 2: Fracture Propagator

• Input: Single voxel features + stress + neighbor stress values
• Output: Fracture probability (0..1)
• Architecture: Small MLP, 16-8-1
• Training: Binary labels from simulation ground truth (voxel broke / didn't break)
• Use case: Determines which stressed voxel breaks next (instead of threshold comparison)

Network 3: Debris Trajectory

• Input: Voxel position, material, fracture force magnitude + direction
• Output: Debris velocity (vx, vy) and angular velocity
• Architecture: 8-4-2 regression
• Training: Collect actual debris motion from Box2D simulation, distill to NN
• Use case: Fast approximate debris without full physics for small fragments

Training Pipeline

• Start with zero training samples
• Every 100 frames, record grid states and outcomes
• When a fracture occurs, record the input state and label (which voxels broke)
• Train networks when sample buffer > threshold (e.g., 200 samples)
• Networks persist to file (JSON serialization) across sessions

---

5. Materials

Definition (consts.lua)

LUA
MATERIALS = {
  wood = {
    color = {0.6, 0.4, 0.2},
    density = 0.6,
    strength = 15,
    fracture_depth = 1,
    elasticity = 0.3,
    friction = 0.5,
    ml_weight = 1.0,
    icon_shape = "rect"
  },
  metal = {
    color = {0.7, 0.7, 0.8},
    density = 1.5,
    strength = 40,
    fracture_depth = 3,
    elasticity = 0.1,
    friction = 0.4,
    ml_weight = 2.0,
    icon_shape = "hex"
  },
  glass = {
    color = {0.4, 0.8, 1.0},
    density = 0.4,
    strength = 5,
    fracture_depth = 1,
    elasticity = 0.05,
    friction = 0.2,
    ml_weight = 0.5,
    icon_shape = "diamond"
  },
  rubber = {
    color = {0.2, 0.2, 0.2},
    density = 0.3,
    strength = 30,
    fracture_depth = 0,
    elasticity = 0.9,
    friction = 0.8,
    ml_weight = 1.5,
    icon_shape = "circle"
  },
  concrete = {
    color = {0.5, 0.5, 0.5},
    density = 1.2,
    strength = 25,
    fracture_depth = 2,
    elasticity = 0.05,
    friction = 0.7,
    ml_weight = 1.2,
    icon_shape = "square"
  },
  explosive = {
    color = {1.0, 0.2, 0.1},
    density = 0.5,
    strength = 1,
    fracture_depth = 0,
    elasticity = 0.0,
    friction = 0.3,
    ml_weight = 0.0,  -- no stress prediction, instant detonation
    icon_shape = "triangle"
  }
}

Reactions

• Metal + Wood: standard collision, metal transfers more stress
• Glass + anything: high stress transfer, glass shatters on impact above threshold
• Rubber + anything: absorbs force, high elasticity bounce
• Concrete + Metal: high compression strength, slow fracture
• Explosive + any: radius-based fracture, force = explosive.power × (1 / distance²)

---

6. Controls (Mobile-First)

All input is processed through screenToGame() coordinate conversion for proper letterboxing.

Touch Gestures

Tool Modes

1. Place — tap to place a 3×3 or 5×5 voxel block of selected material
2. Delete — long press to remove objects
3. Push — drag to apply impulse force to objects in drag path
4. Explode — tap to detonate explosives under cursor radius
5. Grab — drag to pick up and move an object

Visual Feedback

• Press highlight: button pulses with material color
• Drag line: shows force vector with arrow
• Placement preview: ghost voxel grid follows finger before tap

Desktop

• Left click: place / select
• Right click: delete
• Middle drag: pan
• Scroll: zoom
• Space: pause
• R: reset world

---

7. Project Structure

PhyX/
├── SPEC.md
├── conf.lua               ← LÖVE2D window config (1080×1920, mobile-safe)
├── main.lua               ← entry: love.load/udpate/draw/quit, global input handlers
├── src/
│   ├── consts.lua          ← ALL numbers: display dims, material defs, ML params, world size
│   ├── core/
│   │   ├── PhysicsWorld.lua    ← LÖVE2D Box2D wrapper, gravity, boundaries, timestep
│   │   ├── VoxelGrid.lua       ← 2D grid of voxels, spatial hash, neighbor queries
│   │   ├── Material.lua        ← material property definitions + fracture logic
│   │   └── FractureManager.lua ← manages fracture propagation across voxel grids
│   ├── objects/
│   │   ├── Object.lua          ← object: collection of voxels, unified physics body
│   │   ├── Voxel.lua           ← single voxel state + connections
│   │   └── ObjectFactory.lua   ← creates pre-built structures (tower, bridge, wall, etc.)
│   ├── ml/
│   │   ├── NeuralNetwork.lua   ← pure Lua MLP: forward, train, serialize
│   │   ├── StressNet.lua       ← stress prediction network
│   │   ├── FractureNet.lua     ← fracture propagation network
│   │   ├── DebrisNet.lua       ← debris trajectory network
│   │   └── MLManager.lua       ← owns all nets, trains on simulation data, prediction interface
│   ├── ui/
│   │   ├── Toolbar.lua         ← left-side material/tool selection
│   │   ├── HUD.lua             ← top bar: FPS, voxel count, ML status
│   │   ├── ForceSlider.lua     ← bottom force magnitude indicator
│   │   └── PauseMenu.lua       ← pause overlay
│   ├── world/
│   │   ├── World.lua           ← world state: objects, boundaries, ambient particles
│   │   └── Camera.lua          ← pan + zoom, handles input
│   └── render/
│       ├── Renderer.lua        ← main draw loop: background, objects, UI, effects
│       └── Effects.lua         ← vignette, scanlines, particles, stress coloring
├── lib/
│   ├── Font.lua            ← geometric font (from previous project)
│   ├── Haptics.lua         ← mobile vibration feedback
│   └── Serializer.lua      ← JSON save/load for worlds + ML model weights
└── assets/
    └── (no external assets — all procedural/geometric)

---

8. Performance Targets

• Target FPS: 60 on mid-range Android (2020+)
• Max voxels: ~2000 active before degradation
• ML inference budget: <1ms per frame (runs on CPU via pure Lua)
• Physics timestep: fixed 1/120s with accumulator pattern
• Rendering: canvas-based batching, no per-voxel draw calls

---

9. Development Phases

Phase 1: Engine Core (this session)

• Project scaffold
• PhysicsWorld: LÖVE2D gravity, boundaries, bodies
• VoxelGrid: grid data structure, spatial queries
• Material system: definitions, voxel creation
• Object: voxel collection → physics body
• Basic rendering: grid background, voxel drawing with material colors
• Camera: pan + zoom
• Mobile controls: tap to place, drag to apply force
• MLManager: NeuralNetwork base + 3 networks + training pipeline

Phase 2: Fracture System

• FractureManager: stress propagation, voxel separation
• ML stress prediction → fracture triggers
• Debris particle system
• Material-specific fracture behaviors

Phase 3: Sandbox Features

• Pre-built structure templates (bridge, tower, wall)
• Explosive tool
• Save/load worlds
• Particle effects for destruction

Phase 4: Polish

• Sound (optional)
• Performance optimization
• UI polish
• APK build

---

10. Success Criteria (Phase 1)

• World renders with grid background
• Player can tap to place voxel blocks of different materials
• Objects fall under gravity and collide with boundaries
• Drag applies force to objects
• ML networks train on simulation data (stress/fracture/debris)
• Runs at 60fps on desktop
• Touch controls work on mobile
