PuppeteerSwarm

Dynamic Orchestration Multi-Agent System

A centralized policy network (puppeteer) that dynamically selects and sequences specialized agents based on evolving task states, with reinforcement learning to optimize both effectiveness and efficiency.

---

Table of Contents

• Overview

• Architecture

• Installation

• Quick Start

• Creating Swarms

  • Basic Swarm Patterns

  • Domain-Specific Swarms

  • Production Swarms

• Building as a Framework

  • Custom Policy Networks

  • Custom State Encoders

  • Custom Reward Functions

  • Custom Aggregation Strategies

  • Extending ReasoningPath

• Core Components

  • PuppeteerSwarm

  • PuppeteerPolicyJAX

  • StateEncoder

  • ReasoningPath

  • RewardCalculator

  • WorkflowTracker

• Configuration Options

• Advanced Usage

• API Reference

• Dependencies

---

Overview

PuppeteerSwarm implements a novel approach to multi-agent orchestration where a central "puppeteer" policy network learns to dynamically select and sequence specialized agents based on the evolving state of a task. Unlike static pipelines, the puppeteer adapts its agent selection strategy through reinforcement learning (REINFORCE algorithm), optimizing for both task correctness and computational efficiency.

Key Features

• Dynamic Agent Selection: Policy network selects agents based on current task state

• Parallel Reasoning Paths: Explore multiple solution strategies simultaneously

• Reinforcement Learning: REINFORCE algorithm optimizes agent selection over time

• Reward Model Integration: Optional transformer-based state encoding for rich representations

• Flexible Aggregation: Multiple strategies for combining results from parallel paths

• Graph Visualization: Track and visualize agent interaction patterns

---

Architecture

MERMAID

flowchart TB

    subgraph PuppeteerSwarm["PuppeteerSwarm"]

        subgraph Policy["Policy Network (PuppeteerPolicyJAX)"]

            State["State"] --> MLP["MLP"]

            MLP --> ActionProbs["Action Probabilities"]

            ActionProbs --> AgentSelect["Agent Selection"]

        end



        AgentSelect --> Path1["Reasoning Path 1"]

        AgentSelect --> Path2["Reasoning Path 2"]

        AgentSelect --> Path3["Reasoning Path 3"]

        AgentSelect --> PathN["..."]



        Path1 --> Aggregation

        Path2 --> Aggregation

        Path3 --> Aggregation

        PathN --> Aggregation



        subgraph Aggregation["Answer Aggregation"]

            Methods["majority_vote / weighted / first"]

        end

    end



    Aggregation --> Output["Final Answer"]


Execution Flow

MERMAID

sequenceDiagram

    participant User

    participant Swarm as PuppeteerSwarm

    participant Policy as PolicyNetwork

    participant Paths as ReasoningPaths

    participant Agents as Agents



    User->>Swarm: run(task)

    Swarm->>Policy: forward(state)

    Policy-->>Swarm: selected_agents



    loop For each selected agent

        Swarm->>Paths: create ReasoningPath

    end



    loop Until all paths finalized

        Swarm->>Paths: step()

        Paths->>Agents: execute(task)

        Agents-->>Paths: result

        Paths->>Policy: forward(new_state)

        Policy-->>Paths: next_agents

    end



    Swarm->>Swarm: aggregate_answers()

    Swarm->>Policy: update() [REINFORCE]

    Swarm-->>User: final_answer


---

Installation

Prerequisites

• Python 3.9+ (Python 3.11 or 3.12 recommended for Flax compatibility)

• JAX with CPU or GPU support

Install Dependencies

BASH

pip install -r requirements.txt


Optional Dependencies

For reward model-based state encoding:

BASH

pip install transformers torch


For graph visualization:

BASH

pip install networkx matplotlib


---

Quick Start

PYTHON

from swarms.structs.agent import Agent

from puppeteer import PuppeteerSwarm


# Define specialized agents

researcher = Agent(

    agent_name="Researcher",

    system_prompt="You are a research specialist. Analyze and gather information."

)


analyst = Agent(

    agent_name="Analyst",

    system_prompt="You are an analytical expert. Process and interpret data."

)


writer = Agent(

    agent_name="Writer",

    system_prompt="You are a professional writer. Synthesize findings into clear output."

)


# Create PuppeteerSwarm

swarm = PuppeteerSwarm(

    agents=[researcher, analyst, writer],

    name="ResearchSwarm",

    max_parallel_paths=2,

    max_steps=5,

    enable_training=True,

    verbose=True

)


# Run a task

result = swarm.run("Analyze the impact of AI on healthcare and summarize key findings.")

print(result)


---

Creating Swarms

This section provides practical patterns for building swarms tailored to different use cases.

Basic Swarm Patterns

Sequential Processing Swarm

For tasks that benefit from step-by-step processing with potential branching:

PYTHON

from swarms.structs.agent import Agent

from puppeteer import PuppeteerSwarm


# Define agents for a data pipeline

ingester = Agent(

    agent_name="DataIngester",

    system_prompt="Extract and validate raw data from the input. Output structured data."

)


transformer = Agent(

    agent_name="DataTransformer",

    system_prompt="Transform and normalize the data. Apply business rules."

)


validator = Agent(

    agent_name="DataValidator",

    system_prompt="Validate data integrity and flag anomalies."

)


outputter = Agent(

    agent_name="DataOutputter",

    system_prompt="Format and present the final processed data. Say 'TASK COMPLETE' when done."

)


pipeline_swarm = PuppeteerSwarm(

    agents=[ingester, transformer, validator, outputter],

    name="DataPipeline",

    max_parallel_paths=1,  # Sequential processing

    max_steps=4,

    enable_training=True

)


Parallel Exploration Swarm

For tasks requiring multiple perspectives or approaches:

PYTHON

# Define diverse reasoning agents

optimist = Agent(

    agent_name="OptimistAnalyst",

    system_prompt="Analyze from a positive perspective. Identify opportunities and benefits."

)


pessimist = Agent(

    agent_name="PessimistAnalyst",

    system_prompt="Analyze from a critical perspective. Identify risks and challenges."

)


pragmatist = Agent(

    agent_name="PragmatistAnalyst",

    system_prompt="Analyze from a practical perspective. Focus on feasibility and implementation."

)


synthesizer = Agent(

    agent_name="Synthesizer",

    system_prompt="Combine multiple perspectives into a balanced conclusion. Say 'FINAL ANSWER' when done."

)


exploration_swarm = PuppeteerSwarm(

    agents=[optimist, pessimist, pragmatist, synthesizer],

    name="PerspectiveExplorer",

    max_parallel_paths=3,  # Explore multiple paths simultaneously

    max_steps=6,

    aggregation_method="weighted",  # Best path wins

    enable_training=True

)


Domain-Specific Swarms

Code Review Swarm

PYTHON

security_reviewer = Agent(

    agent_name="SecurityReviewer",

    system_prompt="""You are a security expert. Review code for:

    - SQL injection vulnerabilities

    - XSS vulnerabilities

    - Authentication/authorization issues

    - Sensitive data exposure

    Output findings in structured format."""

)


performance_reviewer = Agent(

    agent_name="PerformanceReviewer",

    system_prompt="""You are a performance optimization expert. Review code for:

    - Time complexity issues

    - Memory leaks

    - Inefficient algorithms

    - Database query optimization

    Output findings with severity ratings."""

)


style_reviewer = Agent(

    agent_name="StyleReviewer",

    system_prompt="""You are a code quality expert. Review code for:

    - Naming conventions

    - Code organization

    - Documentation completeness

    - Design pattern usage

    Output actionable improvement suggestions."""

)


report_generator = Agent(

    agent_name="ReportGenerator",

    system_prompt="Compile all review findings into a comprehensive code review report. Say 'REVIEW COMPLETE' when done."

)


code_review_swarm = PuppeteerSwarm(

    agents=[security_reviewer, performance_reviewer, style_reviewer, report_generator],

    name="CodeReviewSwarm",

    max_parallel_paths=3,

    max_steps=8,

    enable_training=True

)


Research Assistant Swarm

PYTHON

literature_searcher = Agent(

    agent_name="LiteratureSearcher",

    system_prompt="Search and identify relevant academic sources, papers, and publications on the given topic."

)


fact_checker = Agent(

    agent_name="FactChecker",

    system_prompt="Verify claims and cross-reference information across multiple sources. Flag uncertainties."

)


summarizer = Agent(

    agent_name="Summarizer",

    system_prompt="Create concise summaries of complex information while preserving key details."

)


citation_manager = Agent(

    agent_name="CitationManager",

    system_prompt="Format citations properly and maintain bibliography. Track source reliability."

)


research_writer = Agent(

    agent_name="ResearchWriter",

    system_prompt="Synthesize research into well-structured academic writing. Say 'RESEARCH COMPLETE' when finished."

)


research_swarm = PuppeteerSwarm(

    agents=[literature_searcher, fact_checker, summarizer, citation_manager, research_writer],

    name="ResearchAssistant",

    max_parallel_paths=2,

    max_steps=10,

    aggregation_method="weighted",

    enable_training=True

)


Production Swarms

With Custom Evaluation

PYTHON

import re


def quality_evaluator(answer: str, task: str) -> bool:

    """Evaluate answer quality based on multiple criteria."""

    if not answer or len(answer) < 50:

        return False



    # Check for completion markers

    completion_markers = ["complete", "final answer", "conclusion", "done"]

    has_completion = any(marker in answer.lower() for marker in completion_markers)



    # Check for structured output

    has_structure = bool(re.search(r'(\d+\.|[-*]|\n\n)', answer))



    # Check relevance (simple keyword overlap)

    task_words = set(task.lower().split())

    answer_words = set(answer.lower().split())

    relevance = len(task_words & answer_words) / len(task_words) if task_words else 0



    return has_completion and has_structure and relevance > 0.2


production_swarm = PuppeteerSwarm(

    agents=my_agents,

    name="ProductionSwarm",

    max_parallel_paths=4,

    max_steps=15,

    correctness_evaluator=quality_evaluator,

    enable_training=True,

    learning_rate=0.0005,

    gamma=0.95

)


With Monitoring and Logging

PYTHON

from loguru import logger


class MonitoredSwarm(PuppeteerSwarm):

    """Production swarm with built-in monitoring."""



    def run(self, task: str) -> str:

        logger.info(f"Starting task: {task[:100]}...")



        try:

            result = super().run(task)



            # Log metrics

            logger.info(f"Completed with {len(self.reasoning_paths)} paths")

            logger.info(f"Final answer length: {len(result)} chars")



            for i, path in enumerate(self.reasoning_paths):

                logger.debug(f"Path {i}: {path.agent_sequence} -> reward: {path.reward}")



            return result



        except Exception as e:

            logger.error(f"Task failed: {e}")

            raise


monitored_swarm = MonitoredSwarm(

    agents=my_agents,

    name="MonitoredProduction",

    max_parallel_paths=3,

    max_steps=10,

    enable_training=True

)


---

Building as a Framework

PuppeteerSwarm is designed to be extensible. This section shows how to customize and extend each component.

Custom Policy Networks

Create your own policy network by extending PuppeteerPolicyBase:

PYTHON

from puppeteer import PuppeteerPolicyBase, WorkflowTracker

from typing import Dict, Any, List, Optional

import numpy as np


class CustomTransformerPolicy(PuppeteerPolicyBase):

    """Custom policy using transformer architecture."""



    def __init__(

        self,

        state_dim: int,

        action_dim: int,

        num_heads: int = 8,

        num_layers: int = 4,

        learning_rate: float = 0.0001,

        gamma: float = 0.99,

        max_agents_per_step: int = 3,

        selection_threshold: Optional[float] = None

    ):

        super().__init__(state_dim, action_dim, learning_rate, gamma,

                         max_agents_per_step, selection_threshold)

        self.num_heads = num_heads

        self.num_layers = num_layers

        self._initialize_transformer()



    def _initialize_transformer(self):

        """Initialize your transformer architecture here."""

        # Example: Use your preferred deep learning framework

        # self.model = TransformerEncoder(...)

        pass



    def forward(self, workflow_tracker: WorkflowTracker, global_info: Dict[str, Any]) -> List[int]:

        """Select agents based on current state using transformer."""

        # Encode state

        state = self._encode_state(workflow_tracker, global_info)



        # Get action probabilities from transformer

        # action_probs = self.model(state)

        action_probs = np.random.dirichlet(np.ones(self.action_dim))  # Placeholder



        return self.select_agents_by_threshold(action_probs)



    def _encode_state(self, workflow_tracker: WorkflowTracker, global_info: Dict[str, Any]) -> np.ndarray:

        """Encode workflow state for transformer input."""

        # Custom encoding logic

        history = workflow_tracker.get_workflow_history()

        # Transform to sequence representation

        return np.zeros((1, self.state_dim))  # Placeholder



    def update(self):

        """Update policy using your training algorithm."""

        # Implement PPO, A2C, or other RL algorithms

        pass


# Use custom policy in swarm

class CustomPolicySwarm(PuppeteerSwarm):

    def __init__(self, agents, **kwargs):

        super().__init__(agents, **kwargs)

        # Replace default policy with custom

        self.policy = CustomTransformerPolicy(

            state_dim=kwargs.get('state_dim', 8192),

            action_dim=len(agents),

            learning_rate=kwargs.get('learning_rate', 0.0001)

        )


MERMAID

classDiagram

    class PuppeteerPolicyBase {

        <<abstract>>

        +state_dim: int

        +action_dim: int

        +forward(workflow_tracker, global_info) List~int~

        +update()

        +select_agents_by_threshold(probs) List~int~

    }



    class PuppeteerPolicyJAX {

        +network: MLP

        +params: dict

        +forward(workflow_tracker, global_info) List~int~

        +update()

    }



    class CustomTransformerPolicy {

        +num_heads: int

        +num_layers: int

        +forward(workflow_tracker, global_info) List~int~

        +update()

    }



    class CustomRuleBasedPolicy {

        +rules: dict

        +forward(workflow_tracker, global_info) List~int~

        +update()

    }



    PuppeteerPolicyBase <|-- PuppeteerPolicyJAX

    PuppeteerPolicyBase <|-- CustomTransformerPolicy

    PuppeteerPolicyBase <|-- CustomRuleBasedPolicy


Custom State Encoders

Build specialized state encoders for your domain:

PYTHON

from puppeteer import StateEncoder

from typing import List, Dict, Tuple, Optional

import numpy as np


class DomainSpecificEncoder(StateEncoder):

    """Custom encoder for domain-specific state representation."""



    def __init__(

        self,

        state_dim: int = 4096,

        domain_vocabulary: Optional[Dict[str, int]] = None,

        use_embeddings: bool = True

    ):

        super().__init__(state_dim=state_dim, use_reward_model=False)

        self.domain_vocabulary = domain_vocabulary or {}

        self.use_embeddings = use_embeddings

        self._initialize_domain_embeddings()



    def _initialize_domain_embeddings(self):

        """Initialize domain-specific embeddings."""

        # Load pre-trained domain embeddings or initialize randomly

        vocab_size = len(self.domain_vocabulary) + 1000  # Buffer for unknown tokens

        self.embeddings = np.random.randn(vocab_size, 128) * 0.1



    def encode(self, workflow_history: List[Dict], task: str) -> Tuple[np.ndarray, Optional[float]]:

        """Encode state with domain-specific features."""

        # Extract domain-specific features

        domain_features = self._extract_domain_features(workflow_history, task)



        # Encode temporal patterns

        temporal_features = self._encode_temporal_patterns(workflow_history)



        # Encode agent interaction patterns

        interaction_features = self._encode_interactions(workflow_history)



        # Combine all features

        combined = np.concatenate([

            domain_features,

            temporal_features,

            interaction_features

        ])



        # Pad or truncate to state_dim

        if len(combined) < self.state_dim:

            combined = np.pad(combined, (0, self.state_dim - len(combined)))

        else:

            combined = combined[:self.state_dim]



        # Normalize

        norm = np.linalg.norm(combined)

        if norm > 0:

            combined = combined / norm



        return combined, None



    def _extract_domain_features(self, history: List[Dict], task: str) -> np.ndarray:

        """Extract features specific to your domain."""

        features = []



        # Example: Extract keywords from domain vocabulary

        for word, idx in self.domain_vocabulary.items():

            if word in task.lower():

                features.append(self.embeddings[idx])



        if features:

            return np.mean(features, axis=0)

        return np.zeros(128)



    def _encode_temporal_patterns(self, history: List[Dict]) -> np.ndarray:

        """Encode temporal patterns in workflow history."""

        # Track agent sequence patterns

        pattern = np.zeros(64)

        for i, entry in enumerate(history[-10:]):  # Last 10 steps

            agent_hash = hash(entry.get('agent', '')) % 64

            pattern[agent_hash] += 1.0 / (i + 1)  # Decay older entries

        return pattern



    def _encode_interactions(self, history: List[Dict]) -> np.ndarray:

        """Encode agent interaction patterns."""

        interaction_matrix = np.zeros((8, 8))  # Max 8 agent types



        for i in range(1, len(history)):

            prev_agent = hash(history[i-1].get('agent', '')) % 8

            curr_agent = hash(history[i].get('agent', '')) % 8

            interaction_matrix[prev_agent, curr_agent] += 1



        return interaction_matrix.flatten()


Custom Reward Functions

Design reward functions tailored to your objectives:

PYTHON

from puppeteer import RewardCalculator

from typing import Dict, Optional

import math


class MultiObjectiveRewardCalculator(RewardCalculator):

    """Reward calculator with multiple optimization objectives."""



    def __init__(

        self,

        quality_weight: float = 0.4,

        efficiency_weight: float = 0.3,

        diversity_weight: float = 0.2,

        safety_weight: float = 0.1,

        max_steps: int = 10,

        target_quality_threshold: float = 0.8

    ):

        super().__init__(max_steps=max_steps)

        self.quality_weight = quality_weight

        self.efficiency_weight = efficiency_weight

        self.diversity_weight = diversity_weight

        self.safety_weight = safety_weight

        self.target_quality_threshold = target_quality_threshold



        # Track history for diversity calculation

        self.path_history: List[List[str]] = []



    def calculate_reward(

        self,

        is_correct: bool,

        step: int,

        tokens: int = 0,

        agent_name: Optional[str] = None,

        task_completed: bool = True,

        quality_score: float = 0.0,

        agent_sequence: Optional[List[str]] = None,

        safety_violations: int = 0

    ) -> float:

        """Calculate multi-objective reward."""



        # Quality component

        quality_reward = self._calculate_quality_reward(is_correct, quality_score, task_completed)



        # Efficiency component

        efficiency_reward = self._calculate_efficiency_reward(step, tokens)



        # Diversity component (encourage exploring different agent sequences)

        diversity_reward = self._calculate_diversity_reward(agent_sequence)



        # Safety component

        safety_reward = self._calculate_safety_reward(safety_violations)



        # Weighted combination

        total_reward = (

            self.quality_weight * quality_reward +

            self.efficiency_weight * efficiency_reward +

            self.diversity_weight * diversity_reward +

            self.safety_weight * safety_reward

        )



        return total_reward



    def _calculate_quality_reward(self, is_correct: bool, quality_score: float, task_completed: bool) -> float:

        """Reward for output quality."""

        if not task_completed:

            return -1.0



        base_reward = 1.0 if is_correct else -0.5

        quality_bonus = quality_score - self.target_quality_threshold



        return base_reward + quality_bonus



    def _calculate_efficiency_reward(self, step: int, tokens: int) -> float:

        """Reward for computational efficiency."""

        # Logarithmic step penalty

        step_penalty = math.log(1 + step) / math.log(1 + self.max_steps)



        # Token penalty (normalized)

        token_penalty = min(tokens / 100000, 1.0)



        return 1.0 - step_penalty - 0.5 * token_penalty



    def _calculate_diversity_reward(self, agent_sequence: Optional[List[str]]) -> float:

        """Reward for exploring diverse agent sequences."""

        if not agent_sequence:

            return 0.0



        # Check similarity to previous paths

        if not self.path_history:

            self.path_history.append(agent_sequence)

            return 0.5  # Neutral for first path



        # Calculate average Jaccard distance to previous paths

        distances = []

        seq_set = set(agent_sequence)



        for prev_seq in self.path_history[-10:]:  # Compare to last 10 paths

            prev_set = set(prev_seq)

            intersection = len(seq_set & prev_set)

            union = len(seq_set | prev_set)

            jaccard_distance = 1 - (intersection / union if union > 0 else 0)

            distances.append(jaccard_distance)



        self.path_history.append(agent_sequence)



        return sum(distances) / len(distances) if distances else 0.5



    def _calculate_safety_reward(self, safety_violations: int) -> float:

        """Penalty for safety violations."""

        return 1.0 - min(safety_violations * 0.5, 1.0)


Custom Aggregation Strategies

Implement sophisticated answer aggregation:

PYTHON

from puppeteer import PuppeteerSwarm, ReasoningPath

from typing import List, Optional

import numpy as np


class ConsensusSwarm(PuppeteerSwarm):

    """Swarm with custom consensus-based aggregation."""



    def __init__(self, agents, consensus_threshold: float = 0.6, **kwargs):

        super().__init__(agents, **kwargs)

        self.consensus_threshold = consensus_threshold



    def _aggregate_answers(self) -> str:

        """Aggregate using semantic similarity consensus."""

        if not self.path_answers:

            return "No answer generated."



        if len(self.path_answers) == 1:

            return self.path_answers[0]



        # Calculate pairwise similarity matrix

        similarity_matrix = self._calculate_similarity_matrix(self.path_answers)



        # Find answer with highest average similarity (consensus)

        avg_similarities = np.mean(similarity_matrix, axis=1)



        # Check if consensus threshold is met

        max_similarity = np.max(avg_similarities)



        if max_similarity >= self.consensus_threshold:

            consensus_idx = np.argmax(avg_similarities)

            return self.path_answers[consensus_idx]

        else:

            # No consensus - return weighted combination or best individual

            return self._synthesize_answers(self.path_answers, avg_similarities)



    def _calculate_similarity_matrix(self, answers: List[str]) -> np.ndarray:

        """Calculate semantic similarity between answers."""

        n = len(answers)

        matrix = np.zeros((n, n))



        for i in range(n):

            for j in range(n):

                if i == j:

                    matrix[i, j] = 1.0

                else:

                    matrix[i, j] = self._semantic_similarity(answers[i], answers[j])



        return matrix



    def _semantic_similarity(self, text1: str, text2: str) -> float:

        """Calculate semantic similarity between two texts."""

        # Simple word overlap similarity (replace with embeddings for production)

        words1 = set(text1.lower().split())

        words2 = set(text2.lower().split())



        intersection = len(words1 & words2)

        union = len(words1 | words2)



        return intersection / union if union > 0 else 0.0



    def _synthesize_answers(self, answers: List[str], weights: np.ndarray) -> str:

        """Synthesize multiple answers when no consensus."""

        # Return highest weighted answer with note about disagreement

        best_idx = np.argmax(weights)



        return f"{answers[best_idx]}\n\n[Note: Multiple reasoning paths reached different conclusions.]"




class VotingSwarm(PuppeteerSwarm):

    """Swarm with ranked-choice voting aggregation."""



    def _aggregate_answers(self) -> str:

        """Use ranked-choice voting based on path rewards."""

        if not self.path_answers:

            return "No answer generated."



        # Create answer -> paths mapping

        answer_paths: Dict[str, List[ReasoningPath]] = {}



        for path, answer in zip(self.reasoning_paths, self.path_answers):

            if answer not in answer_paths:

                answer_paths[answer] = []

            answer_paths[answer].append(path)



        # Calculate vote score for each unique answer

        vote_scores = {}

        for answer, paths in answer_paths.items():

            # Score = sum of path rewards + count bonus

            total_reward = sum(p.reward or 0 for p in paths)

            count_bonus = len(paths) * 0.1  # Bonus for agreement

            vote_scores[answer] = total_reward + count_bonus



        # Return answer with highest vote score

        best_answer = max(vote_scores.keys(), key=lambda a: vote_scores[a])

        return best_answer


Extending ReasoningPath

Customize path behavior for specialized reasoning:

PYTHON

from puppeteer import ReasoningPath, PathState, WorkflowTracker, RewardCalculator

from typing import Dict, Any, Optional

import uuid


class BacktrackingPath(ReasoningPath):

    """Reasoning path with backtracking capability."""



    def __init__(self, *args, max_backtracks: int = 3, **kwargs):

        super().__init__(*args, **kwargs)

        self.max_backtracks = max_backtracks

        self.backtrack_count = 0

        self.checkpoints: List[Dict] = []



    def step(self) -> bool:

        """Execute step with checkpoint creation."""

        # Create checkpoint before step

        self._create_checkpoint()



        # Execute normal step

        result = super().step()



        # Check if we should backtrack

        if self._should_backtrack():

            return self._backtrack()



        return result



    def _create_checkpoint(self):

        """Save current state as checkpoint."""

        checkpoint = {

            'agent_sequence': self.agent_sequence.copy(),

            'workflow_actions': self.workflow_tracker.actions.copy(),

            'workflow_results': self.workflow_tracker.valid_results.copy(),

        }

        self.checkpoints.append(checkpoint)



    def _should_backtrack(self) -> bool:

        """Determine if current path should backtrack."""

        if self.backtrack_count >= self.max_backtracks:

            return False



        # Check for error indicators in recent results

        recent_results = self.workflow_tracker.valid_results[-2:]

        error_indicators = ['error', 'failed', 'unable', 'cannot', 'invalid']



        for result in recent_results:

            if any(indicator in result.lower() for indicator in error_indicators):

                return True



        return False



    def _backtrack(self) -> bool:

        """Restore previous checkpoint and try different path."""

        if not self.checkpoints:

            return False



        self.backtrack_count += 1



        # Pop last checkpoint (the one that led to error)

        self.checkpoints.pop()



        if not self.checkpoints:

            return False



        # Restore previous checkpoint

        checkpoint = self.checkpoints[-1]

        self.agent_sequence = checkpoint['agent_sequence'].copy()

        self.workflow_tracker.actions = checkpoint['workflow_actions'].copy()

        self.workflow_tracker.valid_results = checkpoint['workflow_results'].copy()



        # Mark for re-selection with different agent

        self.state = PathState.ACTIVE

        return True




class HierarchicalPath(ReasoningPath):

    """Reasoning path with hierarchical sub-task decomposition."""



    def __init__(self, *args, max_subtask_depth: int = 2, **kwargs):

        super().__init__(*args, **kwargs)

        self.max_subtask_depth = max_subtask_depth

        self.subtask_stack: List[str] = []

        self.current_depth = 0



    def decompose_task(self, task: str) -> List[str]:

        """Decompose complex task into subtasks."""

        # Override this method with your decomposition logic

        # Example: Use LLM to break down task

        return [task]  # Default: no decomposition



    def step(self) -> bool:

        """Execute step with hierarchical task handling."""

        # Check if current result suggests subtask decomposition

        if self._should_decompose():

            subtasks = self.decompose_task(self.global_info.get('task', ''))

            if len(subtasks) > 1 and self.current_depth < self.max_subtask_depth:

                self._push_subtasks(subtasks)



        return super().step()



    def _should_decompose(self) -> bool:

        """Check if task should be decomposed."""

        recent_results = self.workflow_tracker.valid_results[-1:] if self.workflow_tracker.valid_results else []

        decomposition_signals = ['too complex', 'multiple parts', 'break down', 'subtasks']



        for result in recent_results:

            if any(signal in result.lower() for signal in decomposition_signals):

                return True

        return False



    def _push_subtasks(self, subtasks: List[str]):

        """Push subtasks onto stack."""

        self.subtask_stack.extend(reversed(subtasks[1:]))  # Push all but first

        self.global_info['task'] = subtasks[0]  # Set first as current

        self.current_depth += 1


MERMAID

flowchart TB

    subgraph Framework["PuppeteerSwarm Framework"]

        subgraph Extensible["Extensible Components"]

            Policy["Policy Network"]

            Encoder["State Encoder"]

            Reward["Reward Calculator"]

            Agg["Aggregation Strategy"]

            Path["Reasoning Path"]

        end



        subgraph CustomImpl["Your Custom Implementations"]

            CustomPolicy["CustomTransformerPolicy"]

            CustomEncoder["DomainSpecificEncoder"]

            CustomReward["MultiObjectiveReward"]

            CustomAgg["ConsensusAggregation"]

            CustomPath["BacktrackingPath"]

        end



        Policy -.-> CustomPolicy

        Encoder -.-> CustomEncoder

        Reward -.-> CustomReward

        Agg -.-> CustomAgg

        Path -.-> CustomPath

    end



    CustomImpl --> YourSwarm["Your Custom Swarm"]

    YourSwarm --> Production["Production Deployment"]


---

Core Components

PuppeteerSwarm Class

The main orchestrator that manages multiple parallel reasoning paths and coordinates execution using the centralized policy network.

PYTHON

class PuppeteerSwarm(BaseSwarm):

    def __init__(

        self,

        agents: List[Union[Agent, Callable]],

        name: Optional[str] = "PuppeteerSwarm",

        description: Optional[str] = "Dynamic orchestration multi-agent system",

        max_parallel_paths: int = 4,

        max_steps: int = 10,

        enable_training: bool = True,

        state_dim: int = 8192,

        use_reward_model: bool = True,

        reward_model_name: Optional[str] = None,

        learning_rate: float = 0.0001,

        gamma: float = 0.99,

        max_agents_per_step: int = 3,

        aggregation_method: str = "majority_vote",

        correctness_evaluator: Optional[Callable] = None,

        verbose: bool = False

    )


Methods

| Method | Description |

|--------|-------------|

| run(task: str) -> str | Main execution loop. Starts reasoning, steps through paths, and finalizes. |

| start(task: str) | Initialize reasoning with policy-selected initial agents. |

| step() | Execute one step across all active paths. |

| finalize() -> str | Aggregate results, calculate rewards, and update policy. |

| visualize_graph(output_path: Optional[str]) | Visualize agent interaction graph. |

---

PuppeteerPolicyJAX

JAX+Flax-based MLP policy network that learns optimal agent selection through REINFORCE.

PYTHON

class PuppeteerPolicyJAX(PuppeteerPolicyBase):

    def __init__(

        self,

        state_dim: int,

        action_dim: int,

        hidden_layers: List[int] = [512, 128, 32],

        learning_rate: float = 0.0001,

        gamma: float = 0.99,

        max_agents_per_step: int = 3,

        selection_threshold: Optional[float] = None

    )


Key Features

• MLP Architecture: Configurable hidden layers for flexible capacity

• Threshold Selection: Select multiple agents when probabilities exceed threshold

• REINFORCE Updates: Policy gradient updates with discounted returns

---

StateEncoder

Encodes workflow state into fixed-size vectors for the policy network.

PYTHON

class StateEncoder:

    def __init__(

        self,

        reward_model_name: Optional[str] = None,

        state_dim: int = 8192,

        use_reward_model: bool = True,

        device: str = "cpu"

    )


Encoding Methods

1. Reward Model Encoding (Primary): Uses transformer hidden states for rich semantic representations

2. Simple Encoding (Fallback): Character-based concatenation encoding

---

ReasoningPath

Tracks a single reasoning path through the agent sequence.

PYTHON

class ReasoningPath:

    def __init__(

        self,

        path_id: str,

        policy: Any,

        workflow_tracker: WorkflowTracker,

        global_info: Dict[str, Any],

        max_steps: int = 10

    )


Path States

| State | Description |

|-------|-------------|

| INITIALIZED | Path created but not yet started |

| ACTIVE | Path is actively executing |

| SPLITTING | Path selected multiple agents, will split |

| FINALIZED | Path completed execution |

| DISCARDED | Path abandoned |

---

RewardCalculator

Calculates rewards for REINFORCE training with configurable components.

PYTHON

class RewardCalculator:

    def __init__(

        self,

        correctness_weight: float = 1.0,

        step_penalty_scale: float = 1.0,

        token_cost_scale: float = 0.001,

        agent_factors: Optional[Dict[str, float]] = None,

        max_steps: int = 10,

        growth_rate: float = 10.0

    )


Reward Formula


reward = correctness_reward - step_cost - token_cost + agent_factor


Where:

• correctness_reward: +weight if correct, -weight if incorrect

• step_cost: Logarithmic penalty for number of steps

• token_cost: Linear penalty for token usage

• agent_factor: Agent-specific bonus/penalty

---

WorkflowTracker

Tracks action history and state transitions throughout execution.

PYTHON

class WorkflowTracker:

    def add_action(

        self,

        agent: Union[str, Agent],

        action: str,

        result: str,

        success: bool = True,

        cost: float = 0.0,

        tokens: int = 0

    )


---

Configuration Options

Aggregation Methods

| Method | Description |

|--------|-------------|

| majority_vote | Select most common answer (default) |

| weighted | Select answer from highest-reward path |

| first | Select first completed answer |

Training Parameters

| Parameter | Default | Description |

|-----------|---------|-------------|

| learning_rate | 0.0001 | Adam optimizer learning rate |

| gamma | 0.99 | Discount factor for returns |

| enable_training | True | Enable policy updates |

Execution Parameters

| Parameter | Default | Description |

|-----------|---------|-------------|

| max_parallel_paths | 4 | Maximum concurrent reasoning paths |

| max_steps | 10 | Maximum steps per path |

| max_agents_per_step | 3 | Maximum agents selected per step |

---

Advanced Usage

Custom Correctness Evaluator

PYTHON

def my_evaluator(answer: str, task: str) -> bool:

    """Custom logic to evaluate answer correctness."""

    return "expected_keyword" in answer.lower()


swarm = PuppeteerSwarm(

    agents=my_agents,

    correctness_evaluator=my_evaluator,

    enable_training=True

)


Agent-Specific Reward Factors

PYTHON

from puppeteer import RewardCalculator


calculator = RewardCalculator(

    agent_factors={

        "web_search": -1.5,    # Penalize expensive operations

        "terminator": 0.5,     # Reward clean termination

        "analyzer": -0.5,      # Slight penalty for complex agents

        "default": -1.0

    }

)


Visualizing Agent Graphs

PYTHON

swarm = PuppeteerSwarm(agents=my_agents)

swarm.run("My task")


# Save to file

swarm.visualize_graph(output_path="agent_graph.png")


# Display interactively

swarm.visualize_graph()


---

API Reference

PuppeteerSwarm

PYTHON

PuppeteerSwarm(

    agents: List[Union[Agent, Callable]],  # Required: List of agents

    name: Optional[str],                    # Swarm name

    description: Optional[str],             # Swarm description

    max_parallel_paths: int,                # Max concurrent paths

    max_steps: int,                         # Max steps per path

    enable_training: bool,                  # Enable REINFORCE updates

    state_dim: int,                         # State encoding dimension

    use_reward_model: bool,                 # Use transformer encoding

    reward_model_name: Optional[str],       # HuggingFace model name

    learning_rate: float,                   # Policy learning rate

    gamma: float,                           # Discount factor

    max_agents_per_step: int,               # Max agents per selection

    aggregation_method: str,                # Answer aggregation method

    correctness_evaluator: Optional[Callable],  # Custom evaluator

    verbose: bool                           # Enable verbose logging

)


PathState Enum

PYTHON

class PathState(str, Enum):

    INITIALIZED = "initialized"

    ACTIVE = "active"

    SPLITTING = "splitting"

    FINALIZED = "finalized"

    DISCARDED = "discarded"


---

Dependencies

Required

| Package | Version | Purpose |

|---------|---------|---------|

| numpy | >=1.21.0 | Numerical operations |

| jax | >=0.4.0 | Automatic differentiation |

| jaxlib | >=0.4.0 | JAX backend |

| flax | >=0.7.0 | Neural network library |

| optax | >=0.1.0 | Optimization library |

| swarms | >=2.0.0 | Base agent framework |

Optional

| Package | Version | Purpose |

|---------|---------|---------|

| transformers | >=4.30.0 | Reward model encoding |

| torch | >=2.0.0 | Transformer backend |

| networkx | >=3.0 | Graph operations |

| matplotlib | >=3.7.0 | Visualization |

---

Contributing

Contributions are welcome. Please ensure code follows the project's style guidelines:

• Type annotations on all functions

• Docstrings in Google style

• Logging with Loguru

• Clean, modular code structure

Source: https://github.com/alarmingly/Puppeteer
